Symfony UX Map

EXPERIMENTAL This component is currently experimental and is likely to change, or even change drastically.

Symfony UX Map is a Symfony bundle integrating interactive Maps in Symfony applications. It is part of the Symfony UX initiative.

Installation

Install the bundle using Composer and Symfony Flex:

        1
        $ composer require symfony/ux-map


If you're using WebpackEncore, install your assets and restart Encore (not needed if you're using AssetMapper):

        1
2
        $ npm install --force
$ npm run watch


Configuration

Configuration is done in your config/packages/ux_map.yaml file:

        1
2
3
        # config/packages/ux_map.yaml
ux_map:
    renderer: '%env(resolve:default::UX_MAP_DSN)%'


The UX_MAP_DSN environment variable configure which renderer to use.

Available renderers

Renderer
Google Maps	Install: `composer require symfony/ux-google-map` DSN: `UX_MAP_DSN=google://GOOGLE_MAPS_API_KEY@default`
Leaflet	Install: `composer require symfony/ux-leaflet-map` DSN: `UX_MAP_DSN=leaflet://default`

Usage

Creating and rendering

A map is created by calling new Map(). You can configure the center, zoom, and add markers:

        1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
        namespace App\Controller;

use Symfony\Bundle\FrameworkBundle\Controller\AbstractController;
use Symfony\Component\HttpFoundation\Response;
use Symfony\Component\Routing\Attribute\Route;
use Symfony\UX\Map\InfoWindow;
use Symfony\UX\Map\Map;
use Symfony\UX\Map\Marker;
use Symfony\UX\Map\Point;

final class HomeController extends AbstractController
{
    #[Route('/')]
    public function __invoke(): Response
    {
        // 1. Create a new map instance
        $myMap = (new Map())
            // Explicitly set the center and zoom
            ->center(new Point(46.903354, 1.888334))
            ->zoom(6)
            // Or automatically fit the bounds to the markers
            ->fitBoundsToMarkers()
        ;

        // 2. You can add markers
        $myMap
            ->addMarker(new Marker(
                position: new Point(48.8566, 2.3522),
                title: 'Paris'
            ))

            // With an info window associated to the marker:
            ->addMarker(new Marker(
                position: new Point(45.7640, 4.8357),
                title: 'Lyon',
                infoWindow: new InfoWindow(
                    headerContent: '<b>Lyon</b>',
                    content: 'The French town in the historic Rhône-Alpes region, located at the junction of the Rhône and Saône rivers.'
                )
            ))

            // You can also pass arbitrary data via the `extra` option in both the marker
            // and the infoWindow; you can later use this data in your custom Stimulus controllers
            ->addMarker(new Marker(
                // ...
                extra: [
                    'icon_mask_url' => 'https://maps.gstatic.com/mapfiles/place_api/icons/v2/tree_pinlet.svg',
                ],
                infoWindow: new InfoWindow(
                    // ...
                    extra: [
                        'num_items' => 3,
                        'includes_link' => true,
                    ],
                ),
            )
        ;

        // 3. You can also add Polygons, which represents an area enclosed by a series of `Point` instances
        $myMap->addPolygon(new Polygon(
            points: [
                new Point(48.8566, 2.3522),
                new Point(45.7640, 4.8357),
                new Point(43.2965, 5.3698),
                new Point(44.8378, -0.5792),
            ],
            infoWindow: new InfoWindow(
                content: 'Paris, Lyon, Marseille, Bordeaux',
            ),
        ));

        // 4. And inject the map in your template to render it
        return $this->render('contact/index.html.twig', [
            'my_map' => $myMap,
        ]);
    }
}


To render a map in your Twig template, use the ux_map Twig function, e.g.:

        1
2
3
4
5
        {# to be visible, the map must have a defined height #}
{{ ux_map(my_map, { style: 'height: 300px' }) }}

{# you can add custom HTML attributes too #}
{{ ux_map(my_map, { style: 'height: 300px', id: 'events-map', class: 'mb-3' }) }}


Extend the default behavior

Symfony UX Map allows you to extend its default behavior using a custom Stimulus controller:

        1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
        // assets/controllers/mymap_controller.js

import { Controller } from '@hotwired/stimulus';

export default class extends Controller {
    connect() {
        this.element.addEventListener('ux:map:pre-connect', this._onPreConnect);
        this.element.addEventListener('ux:map:connect', this._onConnect);
        this.element.addEventListener('ux:map:marker:before-create', this._onMarkerBeforeCreate);
        this.element.addEventListener('ux:map:marker:after-create', this._onMarkerAfterCreate);
        this.element.addEventListener('ux:map:info-window:before-create', this._onInfoWindowBeforeCreate);
        this.element.addEventListener('ux:map:info-window:after-create', this._onInfoWindowAfterCreate);
    }

    disconnect() {
        // You should always remove listeners when the controller is disconnected to avoid side effects
        this.element.removeEventListener('ux:map:pre-connect', this._onPreConnect);
        this.element.removeEventListener('ux:map:connect', this._onConnect);
        this.element.removeEventListener('ux:map:marker:before-create', this._onMarkerBeforeCreate);
        this.element.removeEventListener('ux:map:marker:after-create', this._onMarkerAfterCreate);
        this.element.removeEventListener('ux:map:info-window:before-create', this._onInfoWindowBeforeCreate);
        this.element.removeEventListener('ux:map:info-window:after-create', this._onInfoWindowAfterCreate);
    }

    _onPreConnect(event) {
        // The map is not created yet
        // You can use this event to configure the map before it is created
        console.log(event.detail.options);
    }

    _onConnect(event) {
        // The map, markers and infoWindows are created
        // The instances depend on the renderer you are using
        console.log(event.detail.map);
        console.log(event.detail.markers);
        console.log(event.detail.infoWindows);
    }

    _onMarkerBeforeCreate(event) {
        // The marker is not created yet
        // You can use this event to configure the marker before it is created
        console.log(event.detail.definition);
    }

    _onMarkerAfterCreate(event) {
        // The marker is created
        // The instance depends on the renderer you are using
        console.log(event.detail.marker);
    }

    _onInfoWindowBeforeCreate(event) {
        // The infoWindow is not created yet
        // You can use this event to configure the infoWindow before it is created
        console.log(event.detail.definition);
        // The associated marker instance is also available
        console.log(event.detail.marker);
    }

    _onInfoWindowAfterCreate(event) {
        // The infoWindow is created
        // The instance depends on the renderer you are using
        console.log(event.detail.infoWindow);
        // The associated marker instance is also available
        console.log(event.detail.marker);
    }
}


Tip

Read the Symfony UX Map Leaflet bridge docs and the Symfony UX Map Google Maps brige docs to learn about the exact code needed to customize the markers.

Then, you can use this controller in your template:

        1
        {{ ux_map(my_map, { 'data-controller': 'mymap', style: 'height: 300px' }) }}


Backward Compatibility promise

This bundle aims at following the same Backward Compatibility promise as the Symfony framework: https://symfony.com/doc/current/contributing/code/bc.html
